Data Sheet
| General | |
|---|---|
| Manufacturer | Fortinet |
| GTIN-/EAN-Code | 0611003687855 |
| In assortment since | 30.11.2020 |
| Interfaces | |
| 1-GbE-RJ45 Ports | 2x |
| PoE Powered Device (PD) | |
| PoE-PD Ports | 1x |
| PoE PD Standards | IEEE 802.3af PoE, IEEE 802.3at PoE+ |
| PoE-PD Power Consumption | 17W |
| Wireless | |
| Wireless Standards | IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ac Wave 2 |
| MIMO Spezifications | 2x2 |
| Frequency Bands | 2,4 GHz, 5 GHz |
| Channel Grids | 20/40, 20/40/80 |
| Maximum Throughput 2.4 GHz | 574 Mbps |
| Maximum Throughput 5 GHz | 1.2 Gbps |
| Number of Antennas | 4 (3 Dual band Internal Wi-Fi + 1 BLE/ZigBee) |
| Dimensions | |
| Form Factor | Wall and Cell mount |
| Dimensions (WxDxH) | 153mm x 153mm x 53.0mm |
| Weight | 0.54 kg |
| Power Supply | |
| Power Supply | External Power Supply Unit, POE-PD |
| Number of Power Supply Units included / maximum | 0 / 2 |
